Bearing brand：KOHO
Bearing model：6700zz Bearing
Product series：67 series thin-walled bearings
Manufacturer：KOHO
0755-84898749
| series | 67 series-thin-walled bearings | |||
| model | 6700zz/rs/rz/open miniature thin-walled bearings | |||
| Inner diameter (mm) | 10 | |||
| Outer diameter (mm) | 15 | |||
| Width(mm) | OPEN | 4 | ||
| zz | 4 | |||
| Grease rate | 25%~30% | |||
| Sealing method | Open type, metal seal, rubber seal | |||
| Bearing material | Stainless steel, bearing steel, carbon steel | |||
| Clearance (mm) | Minimum (mm) | 0.005 | ||
| Maximum (mm) | 0.013 | |||
| Material | Inner circle | Gcr15 | Testing standard | GB-T 305-1998 |
| Outer ring | Gcr15 | GB-T 305-1998 | ||
| Steel ball | Gcr15 | GB-T 305-1998 | ||
| Dust cover (zz) | SPCC/SUS | GB-T 305-1998 | ||
| Retainer (R) | SUS/MN | - | ||
| grease | LY series | JB-T 8571-1997 | ||
| High temperature resistance (℃) | -50~150 | JB-T 8571-1997 | ||
| Basic dynamic load rating Cr(N) | 855 | |||
| Basic static load rating Cor(N) | 435 | |||
| Allowable number of revolutions | grease | *1000rpm | 56 | |
| Lubricant | 65 | |||
Various types of micro motors, cooling fans, instruments and meters, printers, smart homes, precision instruments, mechanical equipment, household appliances, medical equipment, fishing gear, mining machinery, elevators and accessories industries, precision machine tools and other fields
