Bearing brand：KOHO
Bearing model：681 Bearing
Product series：68 series deep groove ball bearings
Manufacturer：KOHO
0755-84898749
| series | 68 series miniature deep groove ball bearings | |||
| model | 681 Open Miniature Deep Groove Ball Bearing | |||
| Inner diameter (mm) | 1 | |||
| Outer diameter (mm) | 3 | |||
| Width(mm) | OPEN | 1 | ||
| zz | - | |||
| Grease rate | 25%~30% | |||
| Sealing method | Open | |||
| Bearing material | Stainless steel, bearing steel, carbon steel | |||
| Clearance (mm) | Minimum (mm) | 0.005 | ||
| Maximum (mm) | 0.013 | |||
| Material | Inner circle | Gcr15 | Testing standard | GB-T 305-1998 |
| Outer ring | Gcr15 | GB-T 305-1998 | ||
| Steel ball | Gcr15 | GB-T 305-1998 | ||
| Dust cover (zz) | SPCC/SUS | GB-T 305-1998 | ||
| Retainer (R) | SUS/MN | - | ||
| grease | LY series | JB-T 8571-1997 | ||
| High temperature resistance (℃) | -50~150 | JB-T 8571-1997 | ||
| Basic dynamic load rating Cr(N) | 96 | |||
| Basic static load rating Cor(N) | 49 | |||
| Allowable number of revolutions | grease | *1000rpm | 130 | |
| Lubricant | 150 | |||
Various types of micro motors, cooling fans, instruments, printers, smart homes, precision instruments, mechanical equipment, household appliances, medical equipment, fishing gear, mining machinery, elevators and accessories industries, precision machine tools and other fields
