Bearing brand：KOHO
Bearing model：691 Bearing
Product series：69 series deep groove ball bearing
Manufacturer：KOHO
0755-84898749
| series | 69 Series-Metric Deep Groove Ball Bearing | |||
| model | 691 Open Miniature Deep Groove Ball Bearing | |||
| Inner diameter (mm) | 1 | |||
| Outer diameter (mm) | 4 | |||
| Width(mm) | OPEN | 1.6 | ||
| zz | - | |||
| Grease rate | 25%~30% | |||
| series | 69 series deep groove ball bearings | |||
| model | 691 deep groove ball bearing | |||
| Clearance (mm) | Minimum (mm) | 0.005 | ||
| Maximum (mm) | 0.013 | |||
| Material | Inner circle | Gcr15 | Testing standard | GB-T 305-1998 |
| Outer ring | Gcr15 | GB-T 305-1998 | ||
| Steel ball | Gcr15 | GB-T 305-1998 | ||
| Dust cover (zz) | SPCC/SUS | GB-T 305-1998 | ||
| Retainer (R) | SUS/MN | - | ||
| grease | LY series | JB-T 8571-1997 | ||
| High temperature resistance (℃) | -50~150 | JB-T 8571-1997 | ||
| Basic dynamic load rating Cr(N) | 141 | |||
| Basic static load rating Cor(N) | 37 | |||
| Allowable number of revolutions | grease | *1000rpm | 100 | |
| Lubricant | 120 | |||
Various types of micro motors, cooling fans, instruments and meters, printers, smart homes, precision instruments, mechanical equipment, household appliances, medical equipment, fishing gear, mining machinery, elevators and accessories industries, precision machine tools and other fields
